DS-2CD2312WD-I EXIR Turret Network Camera provides important new technology for any security application. The 2.8 mm, 4 mm, 6 mm, 8 mm, and 12 mm lens options provide 92.5° to 22° viewing angles

Feature highlights

• Minimum Illumination: 0.01lux @ (F1.2, AGC ON) , 0 lux with IR
• 1280 x 960 Resolution @ 30 fps
• 2.8 mm, 4 mm, 6 mm, 8 mm, and 12 mm
• H.264+, H.264, MJPEG
• Maximum Frame Rate: 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576), 30 fps (640 x 480)
• EXIR Range up to 100 ft (30 m)
• 12 VDC and PoE (802.3af)

DS-2CD2323G0-I Outdoor IR Turrent Camera provides high definition network output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage.

Feature highlights

• Minimum Illumination: Color: 0.028 Lux @ (f/2.0, AGC on)
• Up to 1920 x 1080 Resolution
• 2.8 mm and 4 mm Fixed Lens Options
• H.265+/H.265/H.264+/H.264
• Main Stream: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
• EXIR 2.0 Range Up to 100 ft (30 m)
• 12 VDC ± 25% (PoE 802.3af), maximum 7.5 W

DS-2CD2343G0-I Outdoor IR Turrent Camera provides high definition network output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage.

Feature highlights

• Minimum Illumination:Color: 0.018 lux @ (f/2.0, AGC on), 0 lux with IR
• Up to 2688 x 1520 Resolution
• 2.8 mm and 4 mm Fixed Lens Options
• H.265+/H.265/H.264+/H.264
• Main Stream: 30 fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
• EXIR 2.0 Range Up to 100 ft (30 m)
• 12 VDC ± 25% (PoE 802.3af), maximum 7.5 W

The Hikvision DS-2CD2343G0-IB Outdoor IR Turrent Camera provides high definition network output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage.

Feature highlights

• Minimum Illumination:Color: 0.018 lux @ (f/2.0, AGC on), 0 lux with IR
• Up to 2688 x 1520 Resolution
• 2.8 mm and 4 mm Fixed Lens Options
• H.265+/H.265/H.264+/H.264
• Main Stream: 30 fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080)
• EXIR 2.0 Range Up to 100 ft (30 m)

The Hikvision DS-2CD2383G0-I Outdoor IR Turrent Camera provides high definition network output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage.

Feature highlights

• Minimum Illumination: Color: 0.028 lux @ (f/2.0, AGC on), 0 lux with IR
• Up to 3840 x 2160 Resolution @ 15 fps
• 2.8 mm Fixed Lens Option
• H.265+/H.265/H.264+/H.264
• Main Stream: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
• EXIR 2.0 Range Up to 100 ft (30 m)
• 12 VDC ± 25% (PoE 802.3af), maximum 7.5 W

The Hikvision DS-2CD2383G0-IB Outdoor IR Turrent Camera provides high definition network output. It supports H.265+ video compression technology, which assures savings in bandwidth and storage.

Feature highlights

• Minimum Illumination: Color: 0.028 lux @ (f/2.0, AGC on), 0 lux with IR
• Up to 3840 x 2160 Resolution @ 15 fps
• 2.8 mm Fixed Lens Option
• H.265+/H.265/H.264+/H.264
• Main Stream: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
• EXIR 2.0 Range Up to 100 ft (30 m)
• 12 VDC ± 25% (PoE 802.3af), maximum 7.5 W

The Hikvision DS-2CD6924G0-IHS PanoVu Panoramic Outdoor Dome Camera features four lenses to stitch together a 180° horizontal field of view (2.8 mm: 90° vertical) in Panorama view. Modes include Panorama1, Panorama + ePTZ, Divided Panorama, and Original for flexible viewing.

Feature highlights

• 180° Splicing Image To Present All Scenes Covered by the Camera
• Built-In Heater, Ultra-Low Temperature Start up to -40° F (-40° C)
• Smart Human Density Counting and Public Behavior Analysis To Increase Public Area Safety
• H.265+, H.264+
• Water/Dust (IP67) and Vandal (IK10) Resistant
• IR Range: Four IR LEDs, up to 66 ft (20 m)
• 12 VDC, 1.6 A, maximum 24 W

The Hikvision DS-2CD6984G0-IHS PanoVu Series of Panoramic Outdoor Dome Cameras feature four lenses to stitch together a 180° horizontal field of view (95° vertical) in Panorama view. Modes include Panorama + ePTZ and Divided Panorama for flexible viewing.

Feature highlights

• Minimum Illumination: Color: 0.012 lux @ (ƒ/1.4, AGC on) B/W: 0.0012 lux @ (ƒ/1.4, AGC on), 0 lux with IR
• Maximum Resolution: (4 x 2032) H × 3616 V @ 30 fps (Divided Panorama), 3840 × 2160 Stitched Panorama Image + 10 ePTZ 1920 × 1080 Images (Panorama + ePTZ)
• Horizontal FOV 180°, Vertical FOV 95°
• Focal Length 2.8 mm, four lenses
• H.265, H.264
• Four IR LEDs, 66 ft (20 m) IR Range
• 12 VDC (802.3at, class 4), 17 W

Hikvision’s DS-2CD6D24FWD-(I)Z(H)(S) 8MP H.265+ EXIR PanoVu Flexible Outdoor Network Camera features 1/2.7" progressive scan CMOS sensorsand four lenses. Each lens supports 1080p at 30fps. Compression up to H.265+ saves bandwidth and storage space.

Feature highlights

• Color: 0.006 lux @ (ƒ/1.2, AGC on), 0.01 lux @ (ƒ/1.6, AGC on) B/W: 0.002 lux @ (ƒ/1.2, AGC on); 0.003 lux @ (ƒ/1.6, AGC on) 0 lux with IR on
• 1920 × 1080 @ 30 fps
• Focal Length: 2.8 mm to 12 mm
• Main stream: H.265+/H.265/H.264+/H.264
• 32 Kbps to 16 Mbps
• 33' to 98' (10 m to 30 m)
• 12 VDC ±25%, 12 W

The Hikvision PanoVu DS-2CD6D52G0-IHS Dual- Directional PanoVu Camera features a dual-lens design to capture two separate wide angle views. Other features include H.265+ video compression, audio I/O, an internal microSD memory card slot (up to 256 GB), and an IR range of up to 33 feet (10 meters).

Feature highlights

• Minimum Illumination Color: 0.009 lux @ (ƒ/1.6, AGC on), B/W: 0.0018 lux @ (ƒ/1.6, AGC on), 0 lux with IR
• 2560 × 1920 @ 30 fps
• Flexible Lens: P: -90° to 90°; T: 0° to 60° (2.8 mm), 0° to 70° (4 mm/6 mm); R: 0° to 355
• H.265+, H.265, H.264+, H.264
• Frame Rate: Main Stream 30 fps (2560 × 1920, 2048 × 1536)
• Built-in MicroSD/SDHC/SDXC Card Slot, up to 256 GB
• 12 VDC, POE (802.3af)

Hikvision’s DS-2CD6D54FWD-(I)Z(H)(S) 20 MP H.265+EXIR PanoVu Flexible Outdoor Network Camera features 1/2.7" progressive scan CMOS sensorsand four lenses. Each lens supports 5 MP at 24 fps. Compression up to H.265+ saves bandwidth andstorage space. EXIR technology (-I) extends the IR range to 98 feet (30 meters).

Feature highlights

• Color: 0.006 Lux @ (F1.2, AGC ON), 0.010 Lux @ (F1.6, AGC ON), B/W: 0.002 Lux @ (F1.2, AGC ON); 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR on
• 2560 x 1920 @ 24 fps
• Main stream: H.265+/H.265/H.264+/H.264
• 2.8mm to 12mm
• 60Hz: 24fps (2560 × 1920, 2048 × 1536, 1920 x 1080,1280 x 720)
• 98ft (30m)
• 12 VDC ±25%, 28 W

Hikvision’s DS-2CD6D54G1-IZS EXIR PanoVu FlexibleOutdoor Network Camera features 1/2.7"progressive scan CMOS sensors and four lenses.Each lens supports a resolution of up to 2560 x1920 at 24 fps. Compression up to H.265+ savesbandwidth and storage space. EXIR technologyextends the IR range to 100 feet (30 meters).

Feature highlights

• Minimum Illumination Color: 0.0125 lux @ (ƒ/1.9, AGC on), B/W: 0.0025 lux @ (ƒ/1.9, AGC on)
• 2560 x 1920 @ 24 fps
• Four Flexible Lenses
• H.265+, H.265, H.264+, H.264
• 6 Behavior Analyses, 4 Exception Detections, and Face Detection
• 100 ft (30 m) IR Range
• IP67, IK10

Hikvision’s DS-2CD6D54G1-ZS/RC PanoVu Flexible Outdoor Network Camera features 1/2.7" progressive scan CMOS sensors and four lenses. Each lens supports a resolution of up to 2560 x 1920 at 24 fps. Compression up to H.265+ saves bandwidth and storage space.

Feature highlights

• Minimum Illumination Color: 0.0125 lux @ (ƒ/1.9, AGC on), B/W: 0.0025 lux @ (ƒ/1.9, AGC on)
• 2560 x 1920 @ 24 fps
• 4 Flexible Lenses
• H.265+, H.265, H.264+, H.264
• x 2-Axis Individual Camera Gimbals
• 100 ft (30 m) IR Range
• IP67, IK10
